| Grade | Density g/cm³ | Hardness HRA | T.R.S Mpa | Recommended Performance & Application |
|---|---|---|---|---|
| YG6A | 14.85 | 92.5 | 2000 | Fine grain alloy, good wear resistance; suitable for forming cutters and wear-resistant parts. |
| YG8 | 14.7 | 89.8 | 2800 | High bending strength; suitable for cutters and wear-resistant parts. |
| YG11 | 14.4 | 88.5 | 2900 | High bending strength; suitable for wear-resistant components. |
| YG15 | 14.0 | 87.0 | 3000 | Suitable for manufacturing punching dies and wear-resistant parts. |
| YG20 | 13.5 | 85.5 | 2800 | High bending strength; suitable for progressive dies and punching dies. |
| YG25 | 13.1 | 81.5 | 2950 | High bending strength; suitable for cutters and heavy-duty wear parts. |
| YS2T | 14.25 | 92.0 | 2500 | Fine grain alloy with high wear and thermal strength; suitable for machining refractory alloys and stainless steel. |
| L (mm) | W (mm) | H (mm) | - | W (mm) | T (mm) | L (mm) |
|---|---|---|---|---|---|---|
| 800 | 800 | 10~80 | 100 | 100 | 6~80 | |
| 600 | 600 | 10~80 | 100 | 50 | 6~80 | |
| 300 | 200 | 10~80 | 100 | 45 | 6~80 | |
| 200 | 200 | 10~80 | 80 | 55 | 6~80 | |
| 150 | 150 | 6~80 | 45 | 25 | 6~80 | |
| 120 | 120 | 6~80 | 18 | 12 | 6~80 |
*Other grades and sizes can be offered as per requirements. HIP sintering is advised for plates with thickness exceeding 10mm.
